UM1811 G3LIB menu
52
4.3 G3LIB information base attributes description
From the G3LIB menu, a set of attributes may be read and written. These attributes are not
specified by the G3-PLC protocol. Here is a brief description of all those attributes:
Table 2. G3LIB real-time engine information base attributes
Real-time engine attributes
RTEFWVERSION The real-time engine firmware version
RTEPROTOVERSION The real-time engine protocol version
RTEDRQUEUESIZE The number of TX packets that could be handled by the real-time engine
RTETXPACKETCOUNT The statistical counter of transmitted packet by the real-time engine
RTERXPACKETCOUNT The statistical counter of correct received packet by the real-time engine
RTEMODE The real-time engine working mode (0 rt-MAC, 1 PHY-only)
RTECAPABILITIES Internal use
RTEVALIDATIONTEST Internal use
Table 3. G3LIB protocol engine information base attributes
Protocol engine attributes
PEFWVERSION The protocol engine firmware version
PEPROTOVERSION The protocol engine protocol version
PEDEBUGLEVEL Debug mode settings
PEMODE The G3-PLC library working mode (0 PHY, 1 MAC,2 ADP, 3 BOOT)
PEUNUSED Unused
PECURRENTTIME Current time in the G3-PLC library
Table 4. PHY layer information base attributes
PHYSICAL layer attributes
PHYCRCERRPKTCOUNT
The statistical counter of the packet received by PHY with error detected by
CRC5
PHYCRCFAILPKTCOUNT
The statistical counter of the packet received by PHY with a correct CRC5 but
with error on the fields range
PHYLASTRCVPKTMODE Last received mode
PHYISFIXEDDT
The DT field has a fixed value specified by the PHYDTValue attribute (0 - DT
has not the fixed value, 1 - DT has a fixed value)
PHYDTVALUE The value of the DT field in PHY FCH of the next frames
PHYISFIXEDPDC
PDC has a fixed value specified by the PHYPDCValue attribute (0 - PDC has
not the fixed value, 1 - PDC has a fixed value)
PHYPDCVALUE The value of the PDC field in PHY FCH of the next frames
PHYRSFAILPKTCOUNT
The statistical counter of the packet received by PHY with errors that can't be
corrected by the Reed-Solomon decoder
