6.4 MLME IB EX menu
Figure 17 shows the explorer menu of the information base for the MAC entity.
Figure 17. MAC information base explorer
This menu offers the same set of commands as the MLME IB ones. The main difference is
the white board where the user may drag and drop any of the elements from the list.
