Stack ST500 User Manual

Operation ST500 Tach-Timer
© Stack Limited
26
Display Layer 2
The display includes the odometer only on the
ST500SR Tach-Timer. It is optional on other
models.
Layer 2 shows the odometer reading and the vehicle speed. On models
that do not have the odometer option available, the odometer part of the
display will be blank.
You must fit and connect the wheel speed sensor to the vehicle before the
Tach–Timer can show speed and odometer distance. Otherwise, the display
will show zero speed and distance.
Press the Driver button to show Layer 3.
Display Layer 3
The Corner Speed function is standard on the
ST500P and M. Optional on other models.
Layer 3 shows the maximum Straight Speed.
This is the latest value trapped by the Tach–Timer for maximum speed
reached along the straight.
Press the Driver button to show Layer 4.
