Installation of Accessories
¾ Safety Sides (Swivelling) (Optional)
Deka
103
3. Hold the safety side (see Fig. 2) close to the long side of the bed.
4. Insert the safety side posts into the sleeves in the holder.
x To do so, press the spring against the safety side posts (see Fig. 2 - ).
x Ensure that the side with the release button is closest to the foot end of the bed (see Fig.
3 - ).
5. Insert the safety side until both ends of it click into place.
x Check that safety side is firmly attached.
6. Attach second safety side to other long side of the bed.
x To do so, repeat steps 1 to 5.
M
Fig. 1
