9.8 Electric Actuator System
9.8.1 Control Units
Beds in the Deka range are supplied with two control units for setting and positioning adjustable
components on a:
x Handset with magnetic locking function (as standard)
x Handset with locking box (optional)
9.8.1.1 Handset with Magnetic Locking Function
Electric bed functions can be operated by the user or the patient using a handset. For safety rea-
sons, individual functions can be locked on the handset. The user must lock adjustments on the
handset if the doctor responsible considers this necessary in view of the clinical condition of the
patient. This is possible using the magnetic locking function.
x Explain the handset functions to the patient!
x The electric motors operate as long as the corresponding buttons are kept pressed.
x Adjustments are possible in both directions.
x The handset can be hung at any position on the bed with an elastic hook.
x The coiled cable provides ample flexibility and freedom of motion.
