x The installation work must be carried out by a person who is skilled in this type of work
(e.g. company technicians).
x After installation, a performance test must be carried out.
17.1 ¾ Safety Sides (Swivelling) (Optional)
Beds in the Deka range can optionally be fitted with ¾ safety sides.
17.1.1 Product Contents per Bed
2 x Safety sides
4 x Holders
8 x Locknuts M8
8 x Interior hex cheese-head screws M8 x 25 mm
8 x Ring spacers Ø 8.4 mm
17.1.2 Installation of ¾ Safety Sides
Please note the following points when installing the safety sides:
x Installation is identical on both the left and right-hand side of the bed.
x The side with the release button must be closest to the foot end of the bed.
x Tools required:
Hex key 6 mm
Open jaw wrench 13 mm
Torque spanner (10 - 60 Nm).
x All screws must be tightened to a torque of 28 Nm.
Proceed as follows to install the first ¾ safety side:
1. Attach 2 x holder, 1 x at head end and 1 x facing centre of bed (see Fig. 1 - )
2. Tighten screws to a torque of 28 Nm.
