Product Description
Technical Data
Deka
35
Type
2 sealed maintenance-free lead-acid battery
Capacity
1.3 Ah
Voltage
24 V DC
Lifespan
Up to 5 years under optimum conditions.
The rechargeable lead-acid battery’s lifespan can be negatively influ-
enced by the following conditions:
1. Increased ambient temperature
2. High number of charging/discharging cycles
3. High discharge depth
4. Frequently leaving the bed in a discharged state without being con-
nected to the mains
(Electric) Backrest Actuator (depending on model)
Remarks
(see below)
Type
LINAK LA 27, not suitable for automatic washing systems
LINAK LA 31, suitable for automatic washing systems
1,2,3,4
Force/lift
3500 N / 200 mm
End position cut-out
Micro-switch, analogue coding
Input voltage
24 V DC
Duty cycle
Intermittent duty: 2 min ON / 18 min OFF
Protection category
IP X6, LA 31, suitable for automatic wash-
ing systems (optional)
Actuator (Electric Motor) Lifting Actuators (depending on model)
Type
LINAK LA 34
1,4,5
Force/lift
10000 N / 170 mm
Input voltage
24 V DC
Duty cycle
Intermittent duty: 2 min ON / 18 min OFF
Protection category
IP X6, suitable for automatic washing sys-
tems (optional)
(Electric) Thigh Rest Actuator (depending on model)
Type
LINAK LA 27, not suitable for automatic
washing systems
LINAK LA 31, suitable for automatic wash-
ing systems
3
Force/lift
6000 N / 70 mm
Input voltage
24 V DC
Duty cycle
Intermittent duty: 2 min ON / 18 min OFF
Protection category
IP X6, LA 31, suitable for automatic wash-
ing systems (optional)
1 : Manual CPR release
4 : Limit switch, direct switching
2 : Manual raising
5 : Safety nut
3 : Only push force – no pull force
