34 MS 341, MS 361, MS 361 C
– Remove the shroud – b 6.2
– Remove the decompression
valve, if fitted – b 6.8
: Install plug (1) 1122 025 2200
and tighten down to 25 Nm.
212RA054
VA
1
2
: Fit spark plug (2) and tighten it
down firmly – b 3.5
– Loosen the muffler screws lightly
– b 6.1
: Fit sealing plate (1)
0000 855 8106 between the heat
shield and cylinder exhaust port
and tighten down the screws
moderately.
VA
212RA055
1
The sealing plate must completely
fill the space between the two
screws.
– Remove the switch shaft –
b 10.1
– Remove the carburetor –
b 12.2.1
– Set the piston to top dead center.
This can be checked through the
inlet port.
: Check that the sleeve (1) and
washer (2) are in place.
VA
212RA056
1
2
: Fit the test flange
1128 850 4200 (1).
: Fit the sleeves (2)
0000 963 1001.
: Fit nuts (3) and tighten them
down firmly.
VA
212RA057
3
1
2
6.3.1 Preparations
