Replacing the drive wheel
The wheel bolts must be tightened in a diago-
nal sequence.
CAUTION
The drive wheel must only be replaced by authorized
service personnel.
Wheel bolts tightening torque
NOTE
The owner must check the wheel bolts and
re-tighten if necessary.
Bolts specification Tightening torque (N·m)
Drive wheel M6X20 10~12
Load wheels M8X16 34~41
Check the hydraulic oil level
WARNING
It is forbidden to add hydraulic oil with impurity.
Do not add hydraulic oil that contains impuri-
ties.
– Lift the platform to the top.
– Press the emergency stop switch.
– Unscrew the oil cap.
– Use a clean cloth to dry the dipstick.
– This oil cap has a dipstick.
Maintenance
5
Maintenance work
1015091 801 1525EN-12/2022 - 06
