Still OCV 01 - Page 78

– Pull out the wrench (4) on the frame;
– Remove the plate (1).
– Release the button(2) on the head of valve.
– Press the emergency lowering switch(3),
anticlockwise rotation of valve. Release
emergency lowering valve. The lift platform
is lowered slowly.
– Press the emergency lowering switch(3)
clockwise rotation of valve, release emer-
gency lowering valve, emergency lowering
valve reposition.
WARNING
You could be struck or crushed by the lowering plat-
form, keep your entire body and head away from
area under platform.
WARNING
Do not climb out while the lift platform is elevated.
The lift mast cannot be climbed safely. An elevated
lift platform has a high center of gravity and can be
tipped easily. Standing on or leaning out from the
outside of a cage rail may cause the lift vehicle to tip
over. Tipping the lift vehicle over can cause severe
injury or death and equipment damage.


Operation
4
Emergency Lowering
 70 5091 801 1525EN-12/2022 - 06
