Charging Procedure
– The battery is charged with an internal
charger.
– Park the truck in the designated charging
area.
– Pull the charger cord (2) from the charg-
er socket of truck and examine it for dam-
age. If undamaged, plug the charger into a
standard 100V ~ 240V, 3-phase, 50/60Hz
wall outlet. As long as the built-in charger
is connected to the outlet, the truck will not
move.
WARNING
Can not climb out while the lift platform is elevated.
The lift mast cannot be climbed safely. An elevated
lift platform has a high center of gravity and can be
tipped easily. Standing on or leaning out from the
outside of a cage rail may cause the lift vehicle to tip
over. Tipping the lift vehicle over can cause severe
injury or death and equipment damage.
Charging indicator
Charging indicator(1)
NO. LED status Phenomenon Cause Remedy Description
1 Red light is on Trouble free / Charging
2 Green light is on Trouble free /
End of charg-
ing
3 Yellow light flash Charger Errors
Eliminate
Charger failure
or replace
4 Solid yellow light Battery Errors
Eliminate bat-
tery failure
Storage
If batteries are taken out of service for a
lengthy period they should be stored in the
fully charged condition in a dry, frost-free
room.
If the battery is not used for an extended pe-
riod, it must receive a supplementary charge
every two months to prevent permanent dam-
age to the battery.
Operation
4
Lithium battery
78 5091 801 1525EN-12/2022 - 06
