STM SatLink VSAT - Mesh VSAT CLI Commands Overview

SatLink VSAT User Guide
Publication no. 101557
Rev 14.1.1-2
Copyright 2006-2012 – STM Group, Inc.
Page 119 (182)
Port No. : 45678
Licenses for SW options:
PEP-TCP
QOS-4
Max Mesh Connections: 8
A SatLink mesh VSAT is autonomous regarding the mesh operation, and there is no need for setting up
any configuration parameters. The mesh operation can be disabled by configuration if desired.
The available mesh CLI commands are listed in the table below.
CLI commands
Available in
Boot
SW
Available in
Application
SW
User
Privilege
Level
dvb mesh enable
x
dvb mesh disable
x
x
dvb mesh show [–config|-links|-routes|-stat]
dvb brx show [-stats]
dvb brx stats [enable | disable]
dvb brx offset <freq>
dvb brx cscLog <value>
X
Table 18: Mesh CLI Commands
 dvb mesh enable, dvb mesh disable
 These CLI commands enable and disable mesh capability of the VSAT. By disabling the mesh
capability, the VSAT is moved to star operation. Note: for a change of this parameter to have
effect, the VSAT must be logged off and logged on again.
 dvb brx show
This command displays the physical layer status.
# dvb brx show
Satellite (DVB) Burst Receiver Status
-------------------------------------
State : Fine Sync
RF to B-band offset : -5622 [Hz]
AGC Status : enabled
AGC Gain (relative) : 41 [dB]
Rx Lband Input Level : -50 [dBm]
Satellite LO : 3300000000 [Hz]
Satellite LO Offset : 0 [Hz]
#
The parameters displayed by this command are explained in the table below.
Field
Explanation
State
The state of the physical layer. Possible values are:
- Initialization (burst receiver in initialization state)
- Wait for CSC (the VSAT is trying to acquire its own
transmitted logon burst)
- Coarse Sync (the burst receiver is synchronized with
