Field
Explanation
more than +/- 52 ticks timing error)
- Fine Sync (the burst receiver is synchronized with less
than +/- 52 ticks timing error)
RF to B-band offset
Total frequency error introduced by the LNB, and receiver
analogue front-end in Hz.
AGC Status
Status of the AGC. Either enabled or disabled.
In normal operating mode, the AGC state shall always be
Enabled.
AGC Gain
Gain applied to the RX chain by the AGC function.
RX Lband Input Level
Unit RX composite input level.
Satellite LO
Satellite Local Osscilator.
Satellite LO Offset
Offset of the Satellite Local Oscilator.
Table 19: dvb brx show Command Parameters
 dvb mesh show –config
This command displays the main mesh configuration as received in mesh logon response in addition to
two local status parameters (mesh capability and DLCP client state). Dynamic Link Control Protocol is
the protocol used by the VSAT and the hub for mesh operation. The client part of DLCP is implemented
in the VSAT. The server part implemented in the hub (DLCP server) is also called a mesh controller.
An example of mesh configuration after successful mesh logon:
#dvb mesh show -config
Satellite Mesh Configuration
--------------------------------
Mesh capability : Enabled
DLCP client state : Connected
Mesh Controller IP Address : 10.10.11.30
Mesh Controller DLCP UDP Port : 49359
Satellite Subnet ID : 1
Satellite Subnet Name : Mesh Subnet 1
Mesh Controller DLCP MCAST Group : 234.5.6.7
Default GW Address : 10.10.46.25
DLCP Version : 1
Max connections : 16
Mesh Address Space
--------------------------------
IP Address Subnet Mask
10.10.46.0 / 255.255.255.0
10.10.47.0 / 255.255.255.0
10.10.48.0 / 255.255.255.0
10.10.49.0 / 255.255.255.0
10.10.50.0 / 255.255.255.0
Hub Address Space
--------------------------------
IP Address Subnet Mask
10.10.11.0 / 255.255.255.0
The explanation of the displayed parameters is given in the following table:
