Publication no. 101557
Rev 14.1.1-2
Copyright 2006-2012 – STM Group, Inc.
Enabled by default. Possible values: enabled, disabled
State of the client controlling mesh operation. One of the
following values: Initialization, Logon Requested, Logon in
progress, Connected, Logon denied.
Mesh Controller IP address
The IP address of the mesh controller, also called DLCP
server.
Mesh Controller DLCP UDP port
The UDP port used for reception and sending DLCP
messages.
ID of the Mesh Satellite Subnet the VSAT is a part of.
The name of the Mesh Satellite Subnet the VSAT is a part of.
Mesh Controller DLCP MCAST Group
Multicast address is the system wide multicast address that
applies to all mesh VSATs, regardless of the mesh satellite
subnet they belong to.
The address of the default GW to be used by the VSAT.
The version of the DLCP protocol used by the mesh
controller (DLCP server).
Max number of mesh connections the VSAT is licensed for.
Address range (destinations) to be reached via dynamic mesh
links.
Address range (destinations) to be reached using star link (via
hub).
Table 20: dvb mesh show -config Command Parameters
dvb mesh show –stat
This command shows accumulated mesh statistics. The statistics are reset if the VSAT is put back to star
operation (by disabling mesh operation).
An example of the values displayed by this CLI command:
# dvb mesh show -stat
Dvb Mesh Statistics
--------------------------------
Logon Error : 0
Max connections : 8
Current connection(s): 2
Pending message(s) : 0
Local Remote
LSE Ok : 0 0
LSE Error : 0 0
LSR Ok : 0 0
LSR Error : 0 0
―Local‖ here denotes link service actions initiated by the VSAT itself. ―Remote‖ denotes the link service
actions initiated by the counterpart. LSE stands for Link Service Establishment. LSR stands for Link
Service Release.
The explanation of the displayed values is given in the table below.
