2) Configure the Receiver parameters as shown in the following table:
Parameter
Description
Auto Start
 On
 Off
Specific for the receiver. When set to "On" the VSAT will automatically acquire the
Forward Link. It is recommended to always set this to ―On‖ for normal operation. Please
always restart the VSAT after saving configuration when having set auto start to ―On‖.
LNB Type
Specifies the LNB type with which the VSAT is configured.
Entry
The web interface allows the configuration of two Forward Link entries for fixed
VSATs:
 Primary: corresponds to ―Index 0‖ of CLI configuration
 Secondary: corresponds to ―Index 1‖ of CLI configuration
The primary entry has higher priority than the secondary entry so the Forward Link
search will start with the primary entry.
If the VSAT has a ―Mobile‖ license the web interface allows the configuration of up to
10 Forward Link entries with up to 10 different priorities [0 – 9].
Symbol Rate (Msps)
The Forward Link symbol rate in Msps.
Frequency (GHz)
Forward Link frequency [kHz].
Mode
Enter the valid modes:
 DVB-S
 DVB-S2
PopId
Population ID to use for Forward Link acquisition. The VSAT will select
which group in the DVB-RCS system it belongs to based on the configured population
ID. The population ID to be used is assigned by the Hub Operator.
Enable
Enable the table entry.
