SatLink VSAT User Guide
Publication no. 101557
Rev 14.1.1-2
Copyright 2006-2012 – STM Group, Inc.
Page 55 (182)
When using the SatLink 4033/4035 Transceiver, the VSAT must be configured with the antenna type in
use in order to calculate the transmitted EIRP correctly. The following antennas are supported:
Antenna #
(type)
Antenna (Ku-band)
Size
21
ASC Signal Type 845TX
0.84m
2
ASC/Andrew/Channel Master Type 960
0.96 m
1
ASC/Andrew/Channel Master Type 123
1.20 m
5
ASC/Andrew/Channel Master Type 184
1.80 m
7
ASC/Andrew/Channel Master Type 244
2.40 m
11
Patriot TX-090KU
0.90 m
12
Patriot TX-100KU
1.00 m
13
Patriot TX-120KU
1.20 m
14
Patriot TX-240KU – BATWING
2.40 m
15
Prodelin Series 1132
1.20 m
16
Prodelin Series 1184
1.80 m
17
Prodelin Series 1250
2.40 m
18
Seatel 2406
0.6m
19
Seatel 4006
1.0m
20
Seatel 6006
1.5m
22
Raven G98
0.98m
6
Visiosat
0.75m
8
Seatel 4003
1.00 m
9
Visiosat KIT 90 EMIT
0.90 m
10
Visiosat KIT 120 EMIT
1.20 m
Table 10: Overview of Supported Antenna Types
Please see Appendix G (Table 22) for more detailed information regarding the antennas that can be used
with the SatLink 403x transceiver.
The VSAT is normally pre-configured to use the Patriot 0.96m antenna. If another antenna listed in the
table above is to be used, please enter the CLI command odu antenna <type> where type is the
antenna number from the first column in the table above.
Example:
# odu antenna 13
This selects the Patriot 1.2 m antenna. Use the command odu show to view the ODU configuration
parameters.
