Example:
# odu show
Antenna
---------------------
Type Patriot TX-090KU - 0.9m
Antenna controller None
Tx Gain at 14.25 GHz 40.9dB
Transmitter (BUC) Configuration
-------------------------------
Type STM SatLink 4033 (14.0-14.5 GHz)
ODU Serial No. 104804030303051100020000
ODU HW Version 3.3
ODU SW Version 1.3
Local oscillator 13.050000 GHz
24V DC supply On
Temperature 12 Deg C
Receiver (LNB) Configuration
----------------------------
Type STM SatLink 403x (10.70-12.75 GHz)
Local oscillator - LO1 10.600000 GHz
Local oscillator - LO2 9.750000 GHz
Oscillator switching frequency 11.700000 GHz
LO Switching mode 22kHz
13/18V DC supply 13V
The SatLink VSAT can be configured with one of the following LNBs:
ODU LNB #
(type)
ODU LNB
STM P/N
Ku-band
20
Invacom SPV-1SM
100816
22
Invacom SPV-30SM
23
Invacom SPV-31SM
30
Zinwell ZK-VJ1
104730
40
JRC NJR2535S
41
JRC NJR2536S
42
JRC NJR2537S
43
JRC NJR2183F
71
AZIMUTH AZ-QLKUF01 4-band
72
SMW Q-PLL Type R
C-band
80
Zinwell ZC-VD1
105267
85
Norsat 8XXX-series
95
NexGenWave NEX-800
Table 11: Overview of supported ODU receivers (LNB)
Enter the CLI command # odu lnb <lnbtype> where lnbtype is the number from the first column
in the table above to configure the correct LNB.
When ODU BUC is chosen to be the SatLink 403x transceiver, the LNB will automatically
be set to the SatLink 403x. The SatLink VSAT will detect the SatLink transceiver model
being used (i.e., SatLink 4033 or 4035) and display the detected model in the ODU
Transmitter (BUC) Type field in the CLI odu show output.
