Stonex S10A GNSS Receiver – User Manual 9
3. S10A standard accessories
3.1. Power supply
Batteries (P/N 30-350170)
The standard configuration contains two batteries with S/N, a slot for
charging the batteries (the battery charger) and one adaptor. The batteries
are “Lithium-Ion” battery (11.1V-3400mAH; 37.7Wh), they features a very
high energy-to-weight ratio respect to Ni-Cd or NiMh batteries, no memory
effect and slow self-discharge when it is not used.
Fig. 3.1 - Lithium-Ion battery
Charger + Adapter (P/N 30-350171 + 30-350072)
The charger can be used for both batteries simultaneously. The lights of the
charger shows if the battery is being charged (red light FULL) or if it is
already charged (green light FULL). Red light POWER shows if the charger is
powered on and there is also a light which turns on in case of too high
temperature (red light TEMP).
Fig. 3.2 - S10A charger and adaptor
