Stonex S10A GNSS Receiver – User Manual 7
2.2. Communications & antennas ports
The S10A communications ports are shown in the following figures 2.11 and
2.12: the left port (5-pins LEMO) is used for external power supply and
external radio, the right port (7-pins LEMO) is used for data transferring
between receiver and computer or between receiver and the Controller.
Figure 2.13 and 2.14 show the UHF radio port and the GPRS antenna port.
Fig. 2.11 - 5-pins LEMO port Fig. 2.12 - 7-pins LEMO port
Fig. 2.13 - UHF antenna port Fig 2.14 - GPRS antenna port
