Stonex S10A GNSS Receiver – User Manual 6
6: SATELLITE led (green):
The led blinks and shows the amount of locked
satellites. It starts to blink every 30 seconds for a
number of times equal to the number of locked
satellites.
7: WiFi Led (green)
WiFi is turned on when the led turns green.
7: POWER led (green and red):
Power led shows 3 different status:
1. Green: power supply in good condition.
2. Red: low power (below 20%).
3. Red blinking and beeping: very low power
(below 10%).
When the status #2 is shown (red) about 1 working hour is left.
External power and internal battery share same power light.
When external power is used, the led indicates external power level.
When the power is below 10%, the red led will flash according to
sampling interval (default is 1 seconds) and you also hear three beep
every 60s.
Fig. 2.9 - WiFi Led
Fig. 2.10 - S10 power led
Fig. 2.8 - S10 satellite led
