Stryker SV1 Service Manual

www.stryker.com SM-7100 REV 01 33
Quick reference replacement parts
Kit name Number Kit contents
Number Name
Quantity
Siderail kit, head end
right, dark blue, see
Siderail head end
assembly on page
82
YM-KIT-100016-B YM-02-143-MN1 Back right siderail
assembly with unit
1
HM-22-1780 3M primer 94
handkerchief
1
HM-02-283 2 mm plastic washer
(10 mm plastic
washer) mould NO
34
4
HM-11-19
Q10 capped snap
ring (DT/6668/44A)
4
HM-12-144 12-144 10 x 128 mm
siderail pin
1
HM-12-145 12-145 10 x 305 mm
siderail pin
1
YM-HM-02-418 Future siderail shock
absorber PLS
2
HM-05-018
M8*90 half thread
steel bolt
1
HM-20-557
Ø15 clips
5
HM-07-03 M8 iron washer 2
HM-08-06
M8 fibered nut
1
HM-20-852
Dark blue (Stryker)
upper right siderail
color sticker
1
