Stryker SV1 Service Manual

34 SM-7100 REV 01 www.stryker.com
Quick reference replacement parts
Kit name Number Kit contents
Number Name
Quantity
Siderail kit, head end
right, dark wood, see
Siderail head end
assembly on page
82
YM-KIT-100016-D YM-02-143-MN1 Back right siderail
assembly with unit
1
HM-22-1780 3M primer 94
handkerchief
1
HM-02-283 2 mm plastic washer
(10 mm plastic
washer) mould NO
34
4
HM-11-19
Q10 capped snap
ring (DT/6668/44A)
4
HM-12-144 12-144 10 x 128 mm
siderail pin
1
HM-12-145 12-145 10 x 305 mm
siderail pin
1
YM-HM-02-418 Future siderail shock
absorber PLS
2
HM-05-018
M8*90 half thread
steel bolt
1
HM-20-557
Ø15 clips
5
HM-07-03 M8 iron washer 2
HM-08-06
M8 fibered nut
1
HM-20-759
08 dark wood future
siderail color back
right
1
