INSTALLATIONSTÛV 21
50 5251
NOT INCLUDED
NOT INCLUDED
Chimney
Anchor
plate
4948
Step 50 Remove the pre-cut rear
openings of the wool support plate and
the center one for the chimney.
Step 51 Cut the two layers of wool as to
match the metal plate holes.
Step 52 Replace the wool support plate
and the two layers of wool around the
convection flanges.
Step 48 Attach the insulated shell above
the fireplace using self-drilling screws (not
included).
Step 49 Attach the anchor plate (not
included) and a first chimney section to
the top of the chimney insulation box. Use
self-drilling screws of your choice (not
included).
