7 Teleservice Application Framework
User Manual 103/374
# If no path is set, default command "killall pppd" will be set and an error message will
be put to stdout.
# Daemon will not be started!
pppd_stop_script /etc/ppp/ppp-stop
# Mux_mode_enabled activates the usage of the gsmMuxd within the ynetworkd
# Per default the "use gsmMuxd modus" is deactivated and so the value is set to 0.
# In case of using the modem with the gsmMuxd, the mux mode has to be enabled (1).
# In that case one mux channel is used for data traffic
# and <gsm_tty_path> is used for sending AT commands to the modem.
# Every value greater than 1 will be automatically set to the default value (0)
mux_mode_enabled 0
# The virtual port of the GSM modem which is reserved for AT command communication.
# Max. path length 255
# If no path is set,the default path "/dev/mux1" will be used!
gsm_tty_path /dev/mux1
# In case the modem is no longer accessible there must be a way to reset the modem.
# Max. path length 255
# If no path is set, an error message will be put on stdout. Daemon will not be started!
modem_restart_script /etc/init.d/scripts/gsm restart
# Time which the ynetworkd waits before it verifies the connection.
# Note: Time will be doubled internally
# Min. search time and default is 5, max. search time 0xFFFFs
# If search time is less than 5, default search time will be set.
ppp_net_search_time 10
# After trying NO_NETWORK_REG_COUNTER times, the GSM modem will restart.
# Min. number of tries and default is 3, max. number of tries is 0xFFFF
# If the tries number is less than 3, default tries number will be set.
NO_NETWORK_REG_COUNTER 3
Section: WLAN settings
# To start and stop connections via WLAN, the ynetworkd uses standard linux tools.
# Set the scripts that have to run to establish and to finish a connection via WLAN.
# Start WLAN connection, i.e. scan for hosts and clients
# Max. path length 255
# If no path is set, an error message will be put on stdout. Daemon will not be started!
wlan_start_script /etc/init.d/scripts/wlan_daemon
# Connect to a host or client
# Max. path length 255
# If no path is set, an error message will be put on stdout. Daemon will not be started!
wlan_connect_script /etc/init.d/scripts/wlan_daemon
# Disconnect WLAN connection from host or client
# Max. path length 255
# If no path is set, an error message will be put on stdout. Daemon will not be started!
wlan_disconnect_script /etc/init.d/scripts/wlan_daemon
# Time that the ynetworkd waits before it verifies the connection.
# Note: Time will be doubled internally.
# Min. search time and default is 5s, max. search time 0xFFFFs
# If search time is less than 5s, default will be set.
wlan_net_search_time 5
# WLAN tx power:
# 1: 10 dBm --> 10 mW
# 2: 15 dBm --> 31 mW
# 3: 20 dBM --> 100 mW
# >3 and default is 15 dBm
wlan_tx_power 2
