13 Qualification Tests
User Manual 367/374
ESD - Component immunity test
method
(powered-up test)
Contact discharge ± 2 kV / ± 4 kV / ± 8 kV
Air discharge ± 4 kV / ± 8 kV / ± 15 kV
2000 Ω / 330 pF, 2000 Ω / 150 pF
ESD - Packaging and handling
(unpowered test)
Contact discharge ± 2 kV / ± 4 kV
Air discharge ± 4 kV / ± 8 kV / ± 25 kV
13.4 Electromagnetic Compatibility CE
Emission standard for residential,
commercial and light-industrial
environments
150 kHz to 30 MHz conducted,
30 MHz to 1 GHz antenna
Immunity for industrial environments -
Electrostatic discharge immunity test
DIN EN 61000-4-2
330 Ω / 150 pF
contact discharge ± 4 kV
air discharge ± 8 kV
Immunity for industrial environments -
Radiated, radio-frequency,
electromagnetic field immunity test
DIN EN 61000-4-3
80 MHz to 1.0 GHz, 10 V/m
1.4 GHz to 2.0 GHz, 3 V/m
2.0 GHz to 2.7 GHz, 1 V/m
3 m, horizontal and vertical
Immunity for industrial environments -
Immunity to conducted disturbances,
induced by radio-frequency fields
DIN EN 61000-4-6
150 kHz to 80 MHz, 10V, 80 % AM, sinus
at 1 kHz
13.5 EMC Radio and Telecommunications Terminal Equipment
(R&TTE) Radio equipment and
telecommunications terminal equipment
ElectroMagnetic Compatibility (EMC)
standard for radio equipment and
services;
Part 1: Common technical requirements
ElectroMagnetic Compatibility (EMC)
standard for radio equipment and
services;
Part 7: Specific conditions for mobile and
