STW TC1 User Manual

13 Qualification Tests
User Manual 366/374
Standard
Test description
Parameter
(50/60 Hz)
for a duration of 60 seconds.
ISO 16750-2
Insulation resistance
Perform a "damp heat cyclic" test in
accordance with
ISO 16750-4, then apply 500 V d.c.
(50/60 Hz)
for a duration of 60 seconds.
13.3 Electromagnetic Compatibility e1/E1
Standard
Test description
Parameter
2006/28/EG
(CISPR25, DIN EN
55025)
Radiated emissions from
components -
ALSE method (emissions antenna)
150 kHz to 3 GHz, 1m, 120 kHz bandwidth
2006/28/EG
(ISO 11452-5/-2)
Radiated immunity
Stripline: 10 kHz - 400 MHz, 200V/m, 80 % AM
Antenna, ALSE: 200 MHz - 3 GHz, 200 V/m,
PM
ISO 7637-2
Voltage transient emissions test
ISO 7637-2
Electrical transient conduction
along supply lines only
Pulse 1 (12 V):
Pulse 1 (24 V):
- 100 V, 5000 pulses, 10

- 600 V, 5000 pulses, 50

Pulse 2a (12 V + 24
V):
Pulse 2b (12 V):
Pulse 2b (24 V):
+ 50 V, 5000 pulses, 2

+ 10 V, 10 pulses
+ 20 V, 10 pulses
Pulse 3a (12 V + 24
V):
Pulse 3b (12 V + 24
V):
- 200 V, 1 hour
+ 200 V, 1 hour
Pulse 4 (12 V):
Pulse 4 (24 V):
- 7 V, 2 pulses
- 16 V, 2 pulses
Pulse 5b (24 V):
US* 23 V, td 200 ms, 4

ISO 7637-3
Test pulse generator -
Fast transient test pulses a and b
24V, Level IV, 60 minutes
pulse a: - 80 V
pulse b: + 80 V
