STW TC1 User Manual

5 Hardware
User Manual 28/374
Type
Maximal
available
counts
Description
Bluetooth
1
Bluetooth V.2.1 + EDR (enhanced data rate)
Bluetooth V.4 (BLE bluetooth low energy)
Class 1 (+17 dBm)
internal or external antenna option (via SMA connector)
WLAN
1
IEEE 802.11 a/b/g/n - 2.4 GHz / 5.5 GHz
Infrastructure mode with WEP64, WEP128, WPA, WPA2
(TKIP/PSK) security
AdHoc mode (WEP)
internal or external antenna option (via SMA connector)
5.2.7 Inputs and Outputs
Type
Maximal
available
counts
Feature
Range
Digital input
1
Maximum input voltage
36 V DC
Internal pull down resistor
10 kOhm
ON-threshold
1.7 V ... 3.3 V
OFF-threshold
0.7 V ... 2 V
Digital Output
1
Maximum output voltage
8 V ... 32 V DC (min. +UB-1 V ... max.
+UB)
Maximum output current
0.5 A (thermal over current limitation)
ON-threshold
1.7 V ... 3.3 V
OFF-threshold
0.7 V ... 2 V
ON state resistor
max. 0.3 Ohm
Internal pull down resistor
10 kOhm
High side switch to +UB
