STW TC1 User Manual

13 Qualification Tests
User Manual 363/374
13 Qualification Tests
13.1 Compliance Information
Standard
Test description
Parameter
Conformity
see Declaration of Conformity
KBA (Kraftfahrt-
Bundesamt)
Certification
see Connecting Guidelines (see
"Connecting Guidelines" on page 33)
EMC corresponds
2004/104/EG; 2009/19/EG ff.
DIN EN 62311
Assessment of electronic and electrical
equipment related to human exposure
restrictions for electromagnetic fields (0 Hz
- 300 GHz)
AT&T Approval
PTCRB Certified
13.2 Electrical Safety
Standard
Test description
Parameter
DIN EN 60204-1
Safety of machinery - Electrical
equipment of machines -
Part 1: General requirements
Compliance with air and creeping
distances
(Covered by software "Integra")
STW Company
Standard
Supply voltage
Operation at minimum and maximum
supply voltage (9-32) V
Duration: 60 minutes
STW Company
Standard
Overvoltage / Undervoltage
Operation at 32.96 V and 5.53 V
(maximum 3 % above maximum supply
voltage and below minimum supply
voltage)
STW Company
Standard
Cable breakage supply lines
Disconnect each single supply line at
minimum supply voltage and maximum
supply voltage
STW Company
Standard
Short circuit strength of signal and
communication lines
Short circuit test of each type of Input and
Output against GND and UB at minimum
supply voltage and maximum supply
voltage.
