STW TC1 User Manual

13 Qualification Tests
User Manual 364/374
Standard
Test description
Parameter
Short circuit test of PWM outputs and
digital outputs
to low resistance loads against GND.
STW Company
Standard
Polarity protection
Interchanged battery terminals
STW Company
Standard
Current consumption
Current consumption without D+ (9 V
UB): 1.42 mA
Current consumption without D+ (16 V
UB): 1.77 mA
Current consumption without D+ (32 V
UB): 2.56 mA
Current consumption with D+ (9 V UB):
361 mA
Current consumption with D+ (16 V UB):
209 mA
Current consumption with D+ (32 V UB):
126 mA
STW Company
Standard
Data retention
Non-volatile memory keep data when
supply voltage is disconnected
NOR-Flash: 20 years
NAND-Flash: 10 years
STW Company
Standard
Load test
Operate 48 hours at minimum
temperature with minimum voltage and
maximum current. ( -40 °C, 9V, 350 mA)
Afterwards operate 48 hours at maximum
temperature with maximum voltage and
maximum current.
(+70 °C, 32V, 350 mA)
ISO 16750-2
Direct current supply voltage
Operation at minimum and maximum
supply voltage
ISO 16750-2
Overvoltage - Systems with 12V / 24V
nominal voltage
24 V system: Apply 36 V for 60 minutes
at a temperature that is 20 °C below the
maximum operating temperature
(=50 °C).
ISO 16750-2
Superimposed alternating voltage
Maximum supply voltage = 16 V (12 V
system) and
Maximum supply voltage = 32 V (24 V
system)
Sweep duration: 120 seconds
Number of sweeps: 5
UN: 24 V: Severity 2: Peak to peak
voltage 4 V
UN: 12 V: Severity 4: Peak to peak
voltage 2 V
