4 Getting Started
User Manual 18/374
4 Getting Started
This chapter describes what to do to get started with your TC1.
4.1 Additional Available Supplies
Additional available supplies for the TC1 that can be ordered from STW:
Development box (see "Connect to Development Box" on page
19) for TC1
Power supply 5 V ... 15 V
(the TC1 needs at least 9 V DC)
Accessories kit for mating connector (see "Connector" on page
35)
4.2 Insert SIM Card
To be able to use the mobile feature of the TC1 a SIM card must be installed. The TC1 can handle any kind of
common network provider. The SIM card slot is located inside the connector.
How to install a SIM card
1. Press the yellow button beside the card tray.
2. Remove the SIM card holder
3. Place the SIM card into the tray.
4. Slide in the fitted holder carefully.
