STW TC1 User Manual

7 Teleservice Application Framework
User Manual 161/374
Parameter
Range
Description
opcn_List
maximum
MAX_DP_NAME_LENGTH
pointer to the name of the variable list
opcn_Name
maximum
MAX_DP_NAME_LENGTH
pointer to the name of the variable
opcn_Type
maximum
MAX_DP_TYPENAME_LENGTH,
allowed types:
"UINT8"
"SINT8"
"UINT16"
"SINT16"
"UINT32"
"SINT32"
"FLOAT32"
"AOBYTE"
"STRING"
pointer to the type of the variable
opcn_Size
maximum
MAX_DP_SIZE_LENGTH,
allowed type size:
"UINT8" = 1
"SINT8" = 1
"UINT16" = 2
"SINT16" = 2
"UINT32" = 4
"SINT32" = 4
"FLOAT32" = 4
"AOBYTE" = sizeof (au8_byte)
"STRING" = strlen (acn_string)
pointer to the size in byte of the type
opcn_Unit
maximum
MAX_DP_METANAME_LENGTH
pointer to the user defined unit of the variable
opcn_Comment
maximum
MAX_DP_METANAME_LENGTH
pointer to the variable description
