6 Software
User Manual 65/374
Get local information
It is possible to read out the local settings of the bluetooth device, such as address, name, class, hci version,....
# hciconfig -a
hci0: Type: BR/EDR Bus: UART
BD Address: 84:DD:20:BD:77:3F ACL MTU: 1021:4 SCO MTU: 180:4
UP RUNNING PSCAN ISCAN
RX bytes:907 acl:0 sco:0 events:40 errors:0
TX bytes:722 acl:0 sco:0 commands:36 errors:0
Features: 0xff 0xfe 0x2d 0xfe 0xdb 0xff 0x7b 0x87
Packet type: DM1 DM3 DM5 DH1 DH3 DH5 HV1 HV2 HV3
Link policy: RSWITCH HOLD SNIFF
Link mode: SLAVE ACCEPT
Name: 'TC3G-141846121005'
Class: 0x100110
Service Classes: Object Transfer
Device Class: Computer, Handheld
HCI Version: 4.0 (0x6) Revision: 0x0
LMP Version: 4.0 (0x6) Subversion: 0x1f40
Manufacturer: Texas Instruments Inc. (13)
Get environmental information
Scan the environment for other devices
# hcitool scan
Scanning ...
00:15:83:41:79:8D TEST-PC
Achieving a bluetooth connection to the TC1 from different operating systems
Connect to TC1 from windows based systems over serial port
Windows 7 or newer operating system based devices can connect to the TC1. The device has to be added with
paring code "0000".
Check the properties of the device to identify the used serial port (e.g. COM13).
The serial port can be selected in a terminal program (e.g. TeraTerm) to connect to the TC1.
Connect to TC1 from windows based systems for file sharing
Windows 7 or newer operating system based devices can connect to the TC1. The device has to be added with
paring code "0000".
In order to send a file via Obex FTP it is possible to add the TC1 as a storage medium.
The default configuration of the TC1 does not need to be changed.
The file sharing folder on the TC1 is /tmp/.
The default configuration of the TC1 does not need to be changed.
