Appendix
NOTE:
Protect the environment and dispose the battery properly.
WARNING
If you notice traces of seeping water, damages, or other defects on the oring, do not use Subgear XP-3G for further
dives.TakeittoanauthorizedSUBGEARUWATECdealerforcheckandrepair.
6. Always insert a new O-ring when you replace the battery and dispose the old O-ring. Make sure
that the new O-ring is in perfect condition, and that O-ring, O-ring groove and the sealing surfaces
are free of dust and dirt. If necessary, clean the parts with a soft cloth. Fit the O-ring in the O-ring
groove of the battery cap.
WARNING
7. UseonlyanoriginalSUBGEARO-ring.ThisO-ringisTeoncoatedanddoesnotrequireadditionallubrication.
8. DonotlubricatetheO-ringasthelubricantwillchemicallyattackthebatterycap.
WARNING
9. Checktheproperpolarityofthebattery.SubgearXP-3Gcanbe damagedifyoudonotinsertthebattery
correctly. Insert the new battery, with “+” pointing outwards, into the battery compartment.
After battery replacement Subgear XP-3G will perform an automatic test (8s) and gives a short beep
when the test is done.
Alignment circles
WARNING
10. The battery cap can be installed with a ±120° offset.The alignment circles are there to ensure proper
positioning of the cap. If the rotation is stopped before alignment, watertightness may not be ensured. If
the rotation is forced beyond the alignment, the cap may break. Damage to Subgear XP-3G due to improper
placement of the battery cap is not covered by warranty.
Push the battery cap firmly down and turn it clockwise until the two circles are aligned.
11. Check Subgear XP-3G by switching on
->15.
