Discovery Delay – Overview DiagramOverview Diagram
10
Revision: 1.2 (7/1/2021)
12. Time Knob
e time knob can be used to alter the milliseconds (in 5ms increments) or BPM
(range 55-250BPM), depending on which is shown on the display� e range in mil-
liseconds accessed by the knob is 40ms - 1100ms� You can manually adjust millisec-
ond/BPM times (in 1ms increments) with the [▲] and [▼] buttons to get specic
delay times�
13. Modulation Depth Knob
e depth knob controls how intense the modulation of the delay is�
14. Modulation Waveform Display & Select Button
is button selects one of the 3 waveforms (Triangle, Sine, and Square) to modulate
the delay time with�
15. Modulation Speed Knob
e speed knob controls the speed of a LFO (low frequency oscillator), which con-
trols the delay time around the center of what is displayed on the display� is results
in a chorus-type eect�
16. Tempo LED
is LED ashes at the tempo of the delay time (Milliseconds)�
17. Tap-Tempo Switch
Tap more than once to set the quarter-note delay time�
