Discovery Delay – Usage CasesUsage Cases
34
Revision: 1.2 (7/1/2021)
Usage Cases
Discovery Analog Delay Into Front of Amp
1. Plug in included 18V DC power supply�
2� Plug guitar into the [INPUT] via 1/4” cable�
3. Plug the [OUTPUT] to the input of your amp via 1/4” cable�
Note:
When plugging the Discovery Analog Delay into the front of an amp, especially a
high-gain amp, it’s easy for your tone to get messy and unwieldy because of the re-
peats being distorted by your amp� You may need to lower the [MIX] and [REGEN]
settings and use the [LO-CUT] and [HI-CUT] to reduce the bass, treble and noise
to clean up the delay to where it sits nicely with your dry signal�
88 88
Use included
18V DC power supply
