Suhr Discovery - Audio and MIDI Connectivity

Discovery Delay – Inputs & OutputsInputs & Outputs
12
Revision: 1.2 (7/1/2021)
4. Output (Mono TS 1/4”)
Plug the output of the eect to the next device.
5. Expression Pedal (Stereo TRS 1/4”)
e expression pedal input allows you to connect a low impedance 10K ohm expres-
sion pedal to control all the knobs per preset� For details on how to use the mapping
process for the expression pedal, refer to page 20�
6. Input (Mono TS 1/4”)
e input should be connected to your guitar, the previous eects output, or the ef-
fects send of an amplier or mixer�
7. MIDI In (5 PIN DIN)
e MIDI IN uses the standard DIN 5 connection for MIDI communication� Uses
for this are changing presets, syncing delay time to MIDI clock, and controlling all
parameters� Refer to the MIDI section in this manual for more information
8. MIDI Out/Thru (5 PIN DIN)
e MIDI OUT/THRU jack is used to pass MIDI communication from the MIDI IN
jack to the next device� Depending on the global settings, this output can be set as a
hardware through for ultra low latency when no MIDI information is to be generat-
ed from the Discovery itself� When set as an output, the Discovery delay can send its
own messages such as Program changes and Controller changes� is can be used to
control other pedals� For more information, refer to the MIDI section on page 23�
