Sumitomo T-400S - Splice and Protection Procedures; Preparation and Operating Procedures

2-1
2. Splice / Protection
[Preparation for splicing]
Before splicing, collect all of the necessary equipment.
[Operating procedures]
The following is a summary of the steps required to make a splice with the fusion
splicer. For further information on each step, please see the page described below.
• T-400S
• Optical fiber being spliced
• Jacket remover
• Fiber cleaver
• Pure (more than 99%) alcohol
• Lint-free gauze wipes
• Fiber protection sleeves*
*Note that the applicable fiber protection sleeves are
different depending on the cleave length.
Turning on the T-400S---Page 2-6
Packing and storage instructions
---Page 3-7
Initial screen---Page 2-7
Splice and heater programs setting
---Page 4-1
Stripping the fiber coating/Cleaning
the bare fiber---Page 2-8
Cleaving the fiber---Page 2-9
Inserting fibers into the splice
r
--Page 2-11
Arc test---Page2 -12
Fiber preparation---Page 2-14
Starting the automatic splice
---Page 2-15
Splice protection---Page 2-19
Daily cleaning and checking up
---Page 3-1
