5-3
Auto start heating
When the fiber is placed into the heat shrink oven, the heating operation is automat-
ically started. There’s no need to press the Heater key.
(See also page 4-11.)
The T-400S is provided with Auto start function that automatically starts the
splicing process and the heating operation.
1. In a high location, fix the T-400S to a tripod with the M8 screw or
1/4-20UNC screw on the bottom of the splicer to prevent the splicer
from dropping.
2. Do not use a tripod with a thread length of >8mm (5/16"). Doing so
can risk damage the fusion splicer.
Tripod fixing screws
Screw hole for
1/4-20UNC screw
The T-400S has screw holes for M8 screw and 1/4-20UNC screw. In a high
location, fix the splicer to a tripod to prevent it from dropping.
Auto start splicing
When the fiber is inserted into the splicer and the hood is closed, the splicing process
is automatically started. There’s no need to press the SET key.
(See also page 4-11.)
Caution
Auto start
Screw hole for
M8 screw
