5-1
Multi clamp
The T-400S has ability to work with standard fiber coating, drop cable sheath and φ3mm
fiber cord sheath under standard specification. Please place fiber in an appropriate po-
sition of the coating clamp according to the coating types.
Coating clamp
Drop cable sheath
φ0.25mm
Bare fiber
8mm
4mm
Open the coating clamp lid
and place fiber in the clamp.
<For standard coating>
<For drop cable>
The T-400S is provided with various functions. Set up the functions as necessary.
For use of 60mm protection sleeve
φ0.25mm
For use of 40mm protection sleeve
Groove
10mm
Bare fiber
10mm
Drop cable sheath
Diameter of fiber coating Applicable cleave length
250μm 5~16 mm
900μm 8~16 mm
Diameter of fiber coating Cleave length φ0.25mm coating length
3.0 mm×2.0 mm
10mm（for 60mm sleeve） 10mm（for 60mm sleeve）
8mm（for 40mm sleeve） 4mm（for 40mm sleeve）
Recommended lengths
5. Other convenient functions
