6-6
<Splice program settings> (Administrator mode)
Item Description
Name Allows to edit splice program name.
Abbreviated name Allows to edit splice program name which is displayed on the
main splice screen.
Template Allows to choose splice program as a template when new splice
program is created.
Note Allows to add a note to the selected splice program (up to 21
characters).
Arc Power
Allows to manually adjust the arc power for fusion splicing. Since
an arc test automatically optimizes the power, it is not necessary
to adjust it manually under normal use. If the level of an arc needs
changing, the arc power should be adjusted manually.
Gapset Position Allows to manually adjust the fiber position for fusion splicing.
Since an arc test automatically optimizes the position, it is not
necessary to adjust it manually under normal use. If the position
needs changing, it should be adjusted manually.
Cleaning Arc Time Sets the cleaning arc time for removing dust from optical fiber.
Cleaning Arc Power Allows to adjust power for cleaning arc based on the standard arc
power.
Gap Sets the gap between fiber end faces before arc fusion.
Cleave Angle Limit Sets the threshold of cleave angle. If a reading exceeds the
threshold, the splicer will give an error.
Arc Time Sets the arc fusion time.
Prefuse Time Sets the time between start of arc fusion and feeding of fibers.
Prefuse Power Sets the power for pre arc fusion.
Overlap Sets the distance of feeding fiber.
Fiber Pulling ON or OFF the action of pulling fiber after overlapping fiber.
Fiber Pulling Start* Sets the time of pulling fiber.
Fiber Pulling Length* Sets the distance of pulling fiber.
Fiber Pulling Speed* Sets the speed of pulling fiber.
*Only visible when “Fiber Pulling” is set to ON.
Administrator menu details
