6-7
Arc discharge
<How an arc discharges and motors run during the splicing process>
(1) Arc time
(2) Prefuse time
(3) Overlap
(4) Arc Power
(5) Cleaning Arc Time
(6) Rearc Time
Motor drive
Item Description
Wavelength
Sets the wavelength for loss estimation calculation.
MFD-L Sets the MFD of left-hand optical fiber.
MFD-R Sets the MFD of right-hand optical fiber.
Minimum Loss
Sets the value to be added to an estimated loss.
Est. Loss Limit Sets the threshold of estimated loss. If a reading exceeds the
threshold, the splicer will give an error.
Rearc Time Sets the time for additional arc to be conducted after splicing.
Rearc Power Sets the power for additional arc to be conducted after splicing.
Proof Test Enables/Disables a proof test to be conducted after the splicing
process. There are 2 options: ON/OFF.
