Installation, Operation, and Maintenance Manual
10 SUMMIT PUMP MODEL 2196 / 2196-LF / 2196-R / 2796
causing severe damage to the impeller
and/or casing.
5. Reinstall the coupling and coupling guard.
6. Unlock power to pump driver.
IMPELLER CLEARANCE
WARNING!
Check impeller clearance prior to starting
pump. Setting may have changed during
transit.
WARNING!
Lock out power prior to working on pump.
Impeller clearance is the measurement between the impeller vanes and the surface of
the casing. This clearance is set at .015 inches during assembly, but may need to be
adjusted before initial startup. (See APPENDIX A for detailed procedures on setting
the impeller clearance.)
PRIMING
Prior to starting a centrifugal pump, it is imperative that you prime the pump by
flooding the suction piping and casing with fluid. Priming will occur when you open
the suction isolation valve and the packing sealing liquid valve.
CAUTION!
Do not operate the pump without liquid in
the casing.
START UP
TO START UP THE PUMP
1. Rotate the pump by hand; making sure that the rotating element is spinning freely.
2. Be sure the suction valve is open.
3. Partially close the discharge valve.
CAUTION!
Do not operate the pump with the
discharge valve closed for an extended
period of time.
