Summit 2196 model - Cartridge Mechanical Seal; Type 1 Mechanical Seal

Installation, Operation, and Maintenance Manual
6 SUMMIT PUMP MODEL 2196 / 2196-LF / 2196-R / 2796
CAUTION!
Do not allow packing to run dry. It must
be lubricated.
See ANSI/ASME B73.1 M-1984 for
proper seal flush plans.
Cartridge Mechanical Seal
WARNING!
Determine the effects that a failure of the
mechanical seal might have on the
environment and personnel and correct
conditions to prevent personal injury.
WARNING!
Only work on seal when the pump is
locked out and the seal is depressurized.
Refer to the Burgmann installation, operating, and maintenance instructions.
Failure to do so can result in environmental damage, personal injury, and seal
malfunction and / or seal failure. Pay particular attention to paragraphs 4.2, 4.3
and 4.4.
Start Up
Read, understand and follow the Burgmann Operation section 4.0, paragraphs 4.1
and 4.2
Storage, Assembly and Disassembly
Refer to the Burgmann Seal Storage assembly and disassembly sections 3.0, 3.1,
3.2, and 3.3, paying particular attention to the seal drawing included in the
instructions.
Type 1 Mechanical Seal
 TO INSTALL TYPE 1 MECHANICAL SEAL
1. MTO, LTO, XLO Slide the stuffing box cover over the shaft/sleeve. Bolt the
cover (184) to the frame adapter(108).
STO Slide the 6” or 8” stuffing box cover (184) with adapter ring (108) over
shaft and bolt to bearing.
2. Mark / scribe the shaft at the face of the stuffing box.
3. Unbolt and remove the stuffing box cover.
