Summit 2196 model - Model 2196 Baseplate Related Dimensions

Installation, Operation, and Maintenance Manual
SUMMIT PUMP MODEL 2196 / 2196-LF / 2196-R / 2796 35
MODEL 2196 BASEPLATE RELATED DIMENSIONS
BASEPLATE RELATED DIMENSIONS
PUMP
FRAME
BASEPLATE
NUMBER
MAX MOTOR
FRAME
HA HB HE HF HP HG HH HL
1
145
10 35 4 32 1/2 1 1/4 3 3/4 4 1/2
2
215
12 39 4 1/2 36 1/2 1 1/4 3 1/4 3/4 4 1/2
STO
3
286
15 46 6 43 1/2 1 1/4 4 1/8 3/4 4 1/2
4
215
12 45 4 1/2 42 1/2 1 1/4 3 3/4 3/4 4 1/2
5
286
15 52 6 49 1/2 1 1/4 4 1/8 3/4 4 1/2
6
365
18 58 7 1/2 55 1/2 1 1/4 4 3/4 1 4 1/2
MTO
7
444
18 60 7 1/2 57 1/2 1 1/4 4 3/4 1 4 1/2
8
286
26 62 9 1/2 59 1/2 1 1/4 4 3/4 1 6 1/2
9
365
22 68 9 1/2 65 1/2 1 1/4 4 3/4 1 6 1/2
XLO
10
447
22 80 9 1/2 77 1/2 1 1/4 4 3/4 1 6 1/2
