Summit 2196 model - Appendix F - Dimensional Data; Model 2196 Dimensional Data

Installation, Operation, and Maintenance Manual
SUMMIT PUMP MODEL 2196 / 2196-LF / 2196-R / 2796 34
APPENDIX F – DIMENSIONAL DATA
MODEL 2196 DIMENSIONAL DATA
2196 DIMENSIONS
PUMP
SIZE FOOT PATTERN SHAFT APPROX.
FRAME
ANSI DIS SUC IMP X D B A SP E1 E2 F H U KEYWAY V
BARE PUMP WT.
(LBS.)
AA 1 1.5 6 85
AB 1.5 3 6 90
STO 2 3 6 6 1/2 5 1/4 4 13 1/2 3 3/4 3 0 7 1/4 5/8 .875 3/16 X 3/32 2 95
AA 1 1.5 8 100
AB 1.5 3 8 110
A60 2 3 8 9 1/2 200
A70 3 4 8 11 MTO MTO 220
MTO A70 3 4 8G 11 1.125 1/4X1/8 220
A05 1 2 10 8 1/2 8 1/4 200
A50 1.5 3 10 8 1/2 220
A60 2 3 10 9 1/2 230
or A70 3 4 10 11 4 19 1/2 3 3/4 4 7/8 3 5/8 12 1/2 5/8 2 5/8 265
A40 3 4 10H 12 1/2 275
A80 4 6 10 13 1/2 305
A80 4 6 10H 13 1/2 305
LTO A20 1.5 3 13 10 1/2 LTO LTO 245
A30 2 3 13 11 1/2 10 1.875 1/2X1/4 275
A40 3 4 13 12 1/2 330
A80 4 6 13 13 1/2 405
A90 6 8 13 16 560
A100 8 10 13 18 670
XLO A110 6 8 15 18 14 1/2 6 27 7/8 5 1/4 8 4 1/2 18 3/4 7/8 2.375 5/8 X 5/16 4 610
A120 8 10 15 19 740
A120 8 10 15G 19 710
