Chapter 1 System Console 3
2. Open a terminal session on the connecting device, and type:
For example, for a server connected to port 10000 on a terminal server whose IP
address is 192.20.30.10, you would type:
▼ To Access the System Console Through the TIP Connection
1. Connect the RJ-45 serial cable and, if required, the DB-9 or DB-25 adapter
provided.
The cable and adapter connect between another Sun system’s serial port (typically
TTYB) and the serial management port on the back panel of the server.
TABLE 1-1 Pin Crossovers for Connecting to a Typical Terminal Server
Server Serial Port (RJ-45 Connector) Pin Terminal Ser ver Serial Port Pin
Pin 1 (RTS) Pin 1 (CTS)
Pin 2 (DTR) Pin 2 (DSR)
Pin 3 (TXD) Pin 3 (RXD)
Pin 4 (Signal Ground) Pin 4 (Signal Ground)
Pin 5 (Signal Ground) Pin 5 (Signal Ground)
Pin 6 (RXD) Pin 6 (TXD)
Pin 7 (DSR /DCD) Pin 7 (DTR)
Pin 8 (CTS) Pin 8 (RTS)
% telnet IP-address-of-terminal-server port-number
% telnet 192.20.30.10 10000
