40 Netra T2000 Server Administration Guide • September 2006
FIGURE 4-1 Location of the Bezel Server Status and Alarm Status Indicators
TABLE 4-3 Bezel Server Status Indicators
Indicator LED Color LED State Component Status
Locator White On Server is identified with the superuser
locator or ALOM setlocator command.
Off Normal state
Fault Amber On The server has detected a problem and
requires the attention of service personnel.
Off The server has no detected faults.
Activity Green On The server is powered up and running the
Solaris Operating System.
Off Either power is not present or the Solaris
software is not running.
Critical (red)
Major (red)
Minor (amber)
User (amber)
Alarm status indicators:
Locator Fault Activity Power
