102 SPARC Enterprise Mx000 Servers Administration Guide • August 2009
I/O Device Mapping on Midrange Servers
TABLE A-5 shows the device mapping on a midrange server. In the device path, x is
LSB-dependent, and is assigned a value as shown in
TABLE A-2.
Internal Devices on Midrange Servers
The internal midrange server devices, which are located at the XSB location 00-0 or
01-0 (regardless of Uni-XSB or Quad-XSB mode), are shown in
TABLE A-6 and
TABLE A-7. In the device path, x is LSB-dependent, and is assigned a value as shown
in
TABLE A-2.
TABLE A-5 I/O Device Mapping on a Midrange Server
Slot Host Bus Adapter Slot Type OpenBoot PROM Device Path
IOU Slot 0 PCI-X /pci@x0,600000/pci@0/pci@8/pci@0,1
IOU Slot 1 PCIe /pci@x0,600000/pci@0/pci@9
IOU Slot 2 PCIe /pci@x1,700000
IOU Slot 3 PCIe /pci@x2,600000
IOU Slot 4 PCIe /pci@x3,700000
TABLE A-6 Internal Devices and Device Paths on the Midrange Servers, IOU#0
XSB 00-0/IOU 0
Accessible Internal
Devices (M4000/M5000) Device Physical Location OpenBoot PROM Device Path
Network Port 0 IOU#0 /pci@x0,600000/pci@0/pci@8/pci@0/network@2
Network Port 1 IOU#0 /pci@x0,600000/pci@0/pci@8/pci@0/network@2,1
HD0 System /pci@x0,600000/pci@0/pci@8/pci@0/scsi@1/disk@0
HD1 System /pci@x0,600000/pci@0/pci@8/pci@0/scsi@1/disk@1
CD-RW/DVD-RW System /pci@x0,600000/pci@0/pci@8/pci@0/scsi@1/disk@3
Tape System /pci@x0,600000/pci@0/pci@8/pci@0/scsi@1/tape@2
