Sunfar C300 Series User Manual

104 SUNFAR C300
C300 series of non-sensor current vector-control inverter manual
4. Usage example
4.1. OrderⅠ
To read slave model of 0
#.
master will send：
2A 30 30 30 30 31 30 30 30 30 31 38 31 0D
5A 00 00 00 00 01 00 00 00 00 00 00 01 0D
Slave will respond：（Inverter with 220V and 0.4KW）
2A 30 30 30 30 33 30 32 30 30 30 30 34 30 32 34 39 0D
5A 00 00 00 00 03 00 02 00 00 00 00 04 00 00 00 09 0D
4.2. Order Ⅱ
To read running parameter of 0
#
slave（namely read d.4, output freq.）
master will send：
2A 30 30 31 30 30 30 30 34 30 31 38 35 0D
5A 00 00 01 00 00 00 00 04 00 00 00 05 0D
Slave will respond：（Return current DC voltage of generatrix is 285V）
2A 30 30 30 30 33 30 30 34 30 31 31 44 30 32 35 44 0D
5A 00 00 00 00 03 00 00 04 00 00 01 1D 00 00 00 25 0D
4.3. Order Ⅲ
To read code parameter of 0
#
slave（namely parameter F0.16）
master will send：
2A 30 30 32 30 30 30 31 30 30 31 38 33 0D
5A 00 00 02 00 00 00 00 10 00 00 00 12 0D
Slave will respond：（Carrier wave freq. is 8KHZ）
2A 30 30 30 30 33 30 31 30 30 30 35 30 30 32 34 39 0D
5A 00 00 00 00 03 00 00 10 00 00 00 50 00 00 00 63 0D
4.4. Order Ⅳ
To modify digit setting freq of 0
#
slave (modify parameter F0.2 as 60.02)
master will send：(To set detect and restart mode)
2A 30 30 33 30 30 30 30 32 31 37 37 32 30 32 35 36 0D
5A 00 00 03 00 00 00 00 02 00 00 17 72 00 00 00 8E 0D
