Sunfar C300 Series User Manual

22 SUNFAR C300
C300 series of non-sensor current vector-control inverter manual
Parameters’
Types
Function Code Name Setting range
Minimum
Setting
Manufacture
Setting
Modify
Limit
F1. 1 Torque Boosting 0.0~20.0（％） 0.1 6.0
F1. 2 Torque boosting pattern 0：Manual 1：Automatic 1 0 ★
F1. 3 Base running frequency 5.00～the upper limit frequency 0.01 50.00
F1. 4 Max outputvoltage 200～500V; 100～250V 1 380V 220V
F1. 5 V/F freq. 3 [F1.7] ~ [F1.3] 0.01 0.0 ★
F1. 6 V/F voltage 3 [F1.8] ~ 100.0(%) 0.1 0.0 ★
F1. 7 V/F freq. 2 [F1.9] ~ [F1.5] 0.01 0.0 ★
F1. 8 V/F voltage 2 [F1.10] ~ [F1.6] 0.1 0.0 ★
F1. 9 V/F freq.1 0.0 ~ [F1.7] 0.01 0.0 ★
F1. 10 V/F voltage 1 [F1.1] ~ [F1.8] 0.1 0.0 ★
F1. 11
DC braking current when
starting
0.0 ～ 100.0（％） 0.1 50.0
F1. 12
DC braking time when
starting
0.0 ～ 20.0 S 0.1 0 ★
F1.13 Reserved
F1.14 Compensate for slip freq. 0～150（％） 1 0
F1.15
Rated voltage of applied
motor
200～500V; 100~250V 1 380V 220V
F1.16 Rated freq. of applied motor 5.00～600.00Hz 0.01 50.00 ★
F1.17
Rated current of applied
motor
0.01～300.0A 0.01 ▲ ★
F1.18 Rated rev of applied motor 300～6000RPM 1 ▲ ★
Primary applied parameter unit
F1.19
Exciting current of
applied motor
[F0.17]/4~[F1.17]×3/4 0.01 ▲ ★
